FedEx UK Carrier Guide

FedEx UK is a courier service that offers domestic and international shipping solutions to more than 220 countries and territories. ShipEngine's integration with FedEx UK lets you connect multiple FedEx accounts, and offers a wide range of services and package delivery solutions that include multi-package shipping, label customisation, third-party billiing, Electronic Customs Information Transmission (ETD) for international shipments, the ablitity to ship with dry ice (subject to agreement and accordance with the terms of your agreement with FedEx), and more.

This guide provides developers an overview of shipping services that FedEx UK offers and the service codes that you will use to create FedEx UK shipments.

Whether you need to create a new FedEx account or are ready to connect an existing one to ShipEngine, the setup guide below can help you get started.

Connect Your Account

ShipEngine API allows you to connect your FedEx UK accounts programmatically without logging in to the ShipEngine API dashboard. This is useful if you have wrapped a custom UI around the ShipEngine API toolset and want to add or disconnect existing carrier accounts without exposing your end users to the API dashboard.

These APIs can be used in parallel with the ShipEngine Partner APIs to programmatically create new ShipEngine users, and then connect existing FedEx UK accounts all via the API without logging into a dashboard. Together these APIs empower you to completely white-label the ShipEngine experience for your end users.

Continue below for instructions on how to programatically connect FedEx UK using the ShipEngine API.

For instructions on connecting FedEx UK via the ShipEngine dashboard, go to our FedEx help article.

FedEx UK Account Information Model

PropertyDescription
nicknamestring, required
A nickname for your account in ShipEngine. Very useful if you have multiple accounts for the same carrier.
account_numberstring, required
first_namestring, required
last_namestring, required
companystring
address1string, required
address2string
citystring, required
postal_codestring, required
country_codestring, required
emailstring, required
phonestring, required
agree_to_eulabool, required

Connect a Fedex UK account

Example Request

POST /v1/connections/carriers/fedex_uk

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
POST /v1/connections/carriers/fedex_uk HTTP/1.1
Host: api.shipengine.com
API-Key: __YOUR_API_KEY_HERE__
Content-Type: application/json
{
"nickname": "My FedEx UK account",
"account_number": "123456789",
"company": "Example Corp.",
"first_name": "John",
"last_name": "Doe",
"phone": "20 5555 5555",
"address1": "77 Netherpark Crescent",
"address2": "Suite 100",
"city": "London",
"postal_code": "ABC 123",
"country_code": "GB",
"email": "[email protected]",
"agree_to_eula": "true"
}

Example Response

1
2
3
{
"carrier-id": "se-1234567"
}

Disconnect a FedEx account

Modify FedEx UK Settings

ShipEngine takes advantage of some of FedEx UK's advanced functionality but does not enable it by default. You can update these settings in the Dashboard or via the API.

Pickup Type

ParameterTypeDescription
pickup_typeenumerated stringDetermines how FedEx will pickup your packages.
none - Not specified
regular_pickup - You already have a daily pickup scheduled with FedEx.
request_courier - You will call FedEx to request a courier.
drop_box - You will drop-off packages in a FedEx drop box.
business_service_center - You will drop-off packages at an authorized FedEx business service center.
station - You will drop-off the package at a FedEx Station.

Common Settings

ParameterDescription
nicknamestring
Nickname for the account that will appear on carrier calls and in the UI.
is_primary_accountbool
Whether or not the account is set to primary, this currently has no function inside of ShipEngine.
signature_imagestring
A Base 64 encoded image of the signature to be used for this account.
letterhead_imagestring
A Base 64 encoded image of the letterhead to be used for this account.

Example Request

PUT /v1/connections/carriers/fedex/:carrier_id/settings

1
2
3
4
5
6
7
8
9
10
11
12
13
14
PUT /v1/connections/carriers/fedex_uk/se-108252/settings HTTP/1.1
Host: api.shipengine.com
API-Key: __YOUR_API_KEY_HERE__
Content-Type: application/json
{
"nickname": "my fedex UK account",
"pickup_type": "regular_pickup",
"smart_post_hub": "dallas_tx",
"smart_post_endorsement": "address_service_requested",
"is_primary_account": "false",
"signature_image" : "base64string",
"letterhead_image" : "base64string"
}

Example Response

On a successful response, you will receive an HTTP status 204.

Example Request

GET /v1/connections/carriers/fedex/:carrier_id/settings

1
2
3
GET /v1/connections/carriers/fedex_uk/se-108252/settings HTTP/1.1
Host: api.shipengine.com
API-Key: __YOUR_API_KEY_HERE__

Example Response

1
2
3
4
5
6
7
8
9
{
"nickname": "my fedex UK account",
"pickup_type": "none",
"smart_post_hub": "none",
"smart_post_endorsement": "none",
"is_primary_account": true,
"signature_image" : "base64string",
"letterhead_image" : "base64string"
}

FedEx Domestic Service Details

ServiceTransit TimeMax WeightCarrier CodeAPI Code
FedEx® Next Day by 9 a.m.Next business day by 9:00 am50kgFEDEX_NEXT_DAY_EARLY_MORNINGfedex_next_day_9am
FedEx® Next Day by 10 a.m.Next business day by 10:00 am50kgFEDEX_NEXT_DAY_MID_MORNINGfedex_next_day_10am
FedEx® Next Day by 12 noonNext business day by 12:00 noon50kgFEDEX_NEXT_DAY_AFTERNOONfedex_next_day_12noon
FedEx® Next DayEnd of next business day50kgFEDEX_NEXT_DAY_END_OF_DAYfedex_next_day
FedEx 1Day® FreightN/AN/AFEDEX_1_DAY_FREIGHTfedex_1_day_freight_gb
FedEx EconomyWithin 2-3 business days50kgFEDEX_DISTANCE_DEFERREDfedex_economy_gb

FedEx International Service Details

ServiceTransit TimeMax WeightMax LxWxHCarrier CodeAPI Code
FedEx Europe First®Mondays to Fridays
Next day delivery √
68 kg274 cm in length,
330 cm in combined length plus girth
EUROPE_FIRST_INTERNATIONAL_PRIORITYfedex_europe_first_gb
FedEx International First®Mondays to Fridays Next day delivery †68 kg274 cm in length,
330 cm in combined length plus girth
INTERNATIONAL_FIRSTfedex_international_first_gb
FedEx International Economy®2-5 days68 kgN/AINTERNATIONAL_ECONOMYfedex_international_economy_gb
FedEx International Economy Freight®N/A> 68kgN/AINTERNATIONAL_ECONOMY_FREIGHTfedex_international_economy_freight
FedEx International Priority Express®Delivery by midday in 1-3 business days to selected destinations in Asia, Canada, Europe and the U.S.68 kgN/AFEDEX_INTERNATIONAL_PRIORITY_EXPRESSfedex_international_priority_express
FedEx International Connect Plus®Delivery to Europe in 1-3 days, the U.S. in 3 days and Asia-Pacific in 3-5 days. ∑68kgN/AFEDEX_INTERNATIONAL_CONNECT_PLUSfedex_international_connect_plus
FedEx International Priority® πBy end of day in 1-3 business days68kgN/AFEDEX_INTERNATIONAL_PRIORITYfedex_international_priority
FedEx® Regional EconomyN/AN/AN/AFEDEX_REGIONAL_ECONOMYfedex_regional_economy
FedEx® Regional Economy FreightN/AN/AN/AFEDEX_REGIONAL_ECONOMY_FREIGHTfedex_regional_economy_freight
  • √ Destinations in Europe: Austria, Belgium, Czech Republic, Denmark, France, Germany, Hungary, Ireland, Italy, Luxembourg, Netherlands, Poland, Spain, Sweden, Switzerland, United Kingdom
    Next day delivery between 9:00 - 10:00 AM
  • † Destinations in Worldwide: Brazil, Canada, India, Mexico, United States, and Puerto Rico
    Next day delivery between 9:00 - 10:00 AM in _Canada_ **
    Next day delivery between 8:00 - 8:30 AM in the _United States_ **
    Next day delivery between 10:00 - 11:30 AM in _Brazil, India, Mexico,_ and _Puerto Rico_ **
  • ∑ Service availability and transit times depend on selected origin and destination postal codes.
  • π As of 5/13/2022: FedEx International Priority® API Code fedex_international_priority_gb has been deprecated. Please use fedex_international_priority as the correct service code.

FedEx Advanced Options

Advanced Options are a property of the shipment that are used to communicate carrier add-ons used to get rates and create labels, such as "Saturday Delivery". Carrier Options are available dynamically at the List Carriers endpoint.

OptionNameDefault ValueDescription
Bill To Partybill_to_partynullDetermines which party is paying for shipping costs. If null, shipping costs will be billed to the connected FedEx account.
recipient - Required for FedEx Ground Collect.
third_party - Bill to an account that is not connected to ShipEngine. When billing to a third party, you may not see rates returned from ShipEngine API. This field must be used in conjunction with the bill_to_country_code, bill_to_postal_code, and bill_to_account fields.
Bill To Accountbill_to_accountnullThe account number that will be charged shipping costs when bill_to_party is third_party
Bill To Postal Codebill_to_postal_codenullThe Postal Code associated with the bill_to_account. This will be validated by FedEx.
Bill To Country Codebill_to_country_codenullThe two-letter country code associated with the bill_to_account as it corresponds to ISO 3166-1 alpha-2.
Collect on Deliverycollect_on_deliverynullObject used to indicate that the shipping cost should be collected by FedEx on delivery of the package. For more information, check our Collect on Delivery Guide.
Contains Alcoholcontains_alcoholfalseIndicates that the shipment contains alcohol.
Delivered Duty Paiddelivered_duty_paidfalseIndicates that the shipper is paying the international delivery duties for this shipment.
Dry Icedry_icefalseIndicates if the shipment contains dry ice
Dry Ice Weightdry_ice_weight0Object used to identify the weight of the dry ice in the shipment.
value - Numeric value for weight
unit - Unit of measurement for weight. Accepts ounce, pound, gram and kilogram.
FedEx Freightfedex_freightnullObject to provide details for FedEx Freight services.
shipper_load_and_count - String required by FedEx for Freight shipments.
booking_confirmation - String required by FedEx for Freight shipments.
Non Machinablenon_machinablefalseIndicates that the package cannot be processed through FedEx sorting machines.
Saturday Deliverysaturday_deliveryfalseAdd On to deliver on Saturday for services that do not otherwise include Saturday Delivery
Third Party Consigneethird-party-consigneenullHides Consignee-specific information on the commercial invoice for international shipments.

To ensure you always have the most up-to-date information, use the List Carrier Advanced Options call.

Adding Shipment Insurance

FedEx supports adding insurance to your shipments. Review the Parcel Insurance page for details on adding shipment insurance with ShipEngine.

INFO: Notes about FedEx and Insurance

OptionDescription
Manifests / End of Day (EOD) formsShipping amount shown on manifests or EODs for FedEx does not include any insurance costs.
No Signature and $500 or more in insuranceIf you select No Signature and try to include $500 or more in insurance, it will override the signature requirement to become Direct Signature Required.
From FedEx Service Guide T&C (PDF): "Shipments with a declared value of less than US$500 may be delivered and released without obtaining a signature when the sender has authorized a release or, at our sole option, upon oral or written instruction from the sender or recipient.”
The label will have the letters “DSR” to indicate Direct Signature Required.
Discrepancy between FedEx rate calculator and ShipEngine rateThe Declared Value in FedEx's rate calculator is not insurance. This value indicates the max FedEx could be held accountable for. So, if you compare this declared value in FedEx to the rate with insurance in ShipEngine, our rate will be higher.

Example Label

This is an example of a label using FedEx UK.

FedEx UK Example Label

You are now ready to create shipments using FedEx via ShipEngine! FedEx service marks are owned by Federal Express Corporation and used with permission.
